Genius iTouch Controls

8 Room Multizone for Farrowing and Nursery Rooms

The world-renowned iTouch series allows for real-time access and 24/7 management of farm installations.  Cutting-edge technology facilitating the management of
ambient air (ventilation, heating, humidity, static pressure, CO2, etc.), animal populations, feed levels/consumption, lighting, and more.  100% FarmQuest compatible, this cloud-based system is essential in optimizing your production efficiency!

One super zone or up to 4 zones amongst which the available inputs and outputs are divided. The iTouch Control system will consist of one master control combined with optional slaves, modules and optional boards to provide a complete ventilation system.

Feeders, feed augers, water meters, poultry scales, bin scales and lights can be assigned to one or more zones. The Genius iTouch control has built in Wi-Fi to enable access to the FarmQuest where you can manage your operation from anywhere internet is available to your PC or Smart phone.

Exacon has created two models: a base model from which you can add optional boards to suit your application or a deluxe model with optional boards pre-installed. Both models can be one large zone, two zone, three zone, or four zone.

iTouch Master Control Models: Deluxe Model Kit

(mostly suited for poultry applications)

This deluxe model includes the following input and communication boards: X1199, X1201, X1205 8 pot. board, X1276, X1399 boards (8 input configurable). Also includes 12 communication ports for various options. The deluxe model will then provide the following possible options by adding just the required hardware or items:

• 10 temperature inputs or up to 16*
• 4 duration sensors inputs (current sensor for feed) or up to 12*
• 4 pulse count input (water meter) or up to 12*
• 4 humidity probes options
• 4 bird scales comm. ports
• 4 bin scales communication ports
• 4 GEV2/S/LED for 120V modules c/w manual overrides for LED lights
• 4 GEV//MS or GE/MS 0-10V modules c/w manual overrides for variable stages or frequency drives
• 2 0-10v outputs for variable stage modules or frequency modules
• 1 communication port for GE-CBW batch feeding module
• X1399 board provides 8 configurable inputs that would increase the capacity for 8 additional or a combination of 8 temperature probes, duration counters (current sensors), or pulse counters (water meters)
• Additional 8 or 16 potentiometer inlets can be added by adding one or two X1205 8 pot board
• NOTE: A relay slave would likely be required

iTouch Master Control Models: Base Model

(mostly suited for swine, dairy and some types of poultry)

*Includes the following input and communication boards x1199 and x1205 potentiometer board.

The base model will then provide for the following possible options by adding the required hardware or items:

• 10 temperature inputs
• 2 static pressure probes
• 4 duration sensor inputs
• 2 bin scales
• 4 pulse count (water meters)
• 8 potentiometer inlet/curtain actuators
• 2 humidity probes

Includes 2 communication ports that each port can be used for two of the following 3 choices:

• 1-2 bird scales port 1 OR 1-2 light modules port 2
• 1-2 bird scales port 1 OR 1-2 light module port 1 AND 1-2 feed tanks port 2
• Note: Two different uses cannot be used on one communication port. Additional potentiometer inlets can be added but requires the X1205 pot board, X1276, and X1399 board.

PLEASE CALL EXACON SALES STAFF FOR ASSISTANCE ON PRICING ITOUCH CONTROL SYSTEMS. Control can be ordered from Monitrol pre-programmed for special project with 6 weeks advanced ordering. Charges are applicable for on site set up of ITOUCH controls. Allow 2 weeks notice for set up appointments.

*Will be installed at Exacon in relays 1-5

*Will be installed at Exacon in relays 1-5 and 6-10

*Will be installed at Exacon in relays 1-5, or 1-5 and 6-10

EXPANSION RELAY AND VARIABLE SPEED SLAVE MODULE

One of the above modules can be connected to the deluxe model. Base model control must have the optional X1276 board to connect the above modules.

** If the above relay modules are providing additional pot inlets to the eight provided in the Itouch master than add one X1205 8 pot board or two x1205 8 pot board if 16 inlets are required (refer to page 4.11B)

BIRD WEIGHING OPTIONS

FEED BIN SCALES

Base model can operate up to two bin scales. Deluxe model can operate up to 4 bin scales.

WEATHER STATION

Note: Above for iTouch control only for natural curtain logic.

OPTIONAL BOARDS

Note: If you add a X1399 board you must first have a X1276 board installed in the master control

iTOUCH UPGRADE DOOR KIT

**It is possible to upgrade GE-425LS and GE-430LS to iTouch controls with the following door kit and slim board ** Existing toggles need to be used.

Note: It will require new set up of control on site.

BATCH FEEDING OPTIONS

Note: Strongly recommended to use for batch feeding systems with iTouch.

REPLACEMENT BOARDS
