Details for Multiheat Hog Heat Superior
Saving energy and optimizing the climate inside a hog house are top priorities for every pig farmer. The Hog Heat Superior heater by Multiheat is a top-quality, compact and powerful solution.
- High Air Capacity of 1,600 m³/hr (940 cfm)
- Double Epoxy Coating increases durability in corrosive environments
- Produces dry warm air, resulting in less ammonia
- No open flame reduces CO2 and noxious gases inside your pig barn
- Complete unit weighs 53 lbs
- Energy Efficient Multifan motor
- Measurements (H x W x D)- 21″ x 19″ x 20″
Multiheat Hog Heat Superior (Technical Data)
| PART # |
DESCRIPTION |
| E68-8754 |
HOG HEAT SUPERIOR 240V |
| E68-8754-120 |
HOG HEAT SUPERIOR 120V |
| OPTIONAL |
|
| E68-8728 |
DN 15 X 2000MM HOSE (2 per heater required) |
| |
HANGING HARDWARE SUPPLIED SEPARATELY |
TECHNICAL DATA
| WATER SUPPLY / RETURN |
AMBIENT TEMPERATURE |
OUTPUT / WATER FLOW / RESISTANCE |
| 90/70°C – 194/158°F |
20°C – 68°F |
16 kW / 0.7 m3/h / 7.8 kPa – 54,600 BTU / 3.1 gpm / 31 wc |
| 90/70°C – 194/158°F |
30°C – 86°F |
13 kW / 0.6 m3/h / 5.5 kPa – 44,360 BTU / 2.6 gpm / 22 wc |
| 80/65°C – 176/149°F |
20°C – 68°F |
14 kW / 0.9 m3/h / 10.6 kPa – 47,770 BTU / 4.0 gpm / 43 wc |
| 80/65°C – 176/149°F |
30°C – 86°F |
11 kW / 0.7 m3/h / 7.1 kPa – 37,530 BTU / 3.1 gpm / 29 wc |
